City Water Supply Horizontal Fire Fighting Pump Set With Control Cabinet

Ask Lasest Price
Brand Name :	Yuzhou
Model Number :	ISW
Certification :	ISO/SGS/CE
Price :	Negotiable
Payment Terms :	T/T, Western Union
Supply Ability :	500 sets/month
Delivery Time :	3-7 working days

Add to Cart

Product Details
Company Profile

City Water Supply Horizontal Fire Fighting Pump Set With Control Cabinet

Single Stage Horizontal Vertical Centrifugal Water Pump Fire Pump Complete Set Of Equipment With Control Cabinet

Application:

Introduction:

This pump series is used for industrial and city water supply, water drainaga, and widely used for agricultural irrigation, transportation pure water or other liquids which physical and chemical nature is similar to pure water.

Working Scope:

1. Water Pressure: 0.3-1.2MPa (30-120m)

2. Flow Range: 10-320L/S , 150GPM-5000GPM(U.S)
3. Power: 7kW-550kW
4. Speed Scope: 1500-3000r/min
5. Permissible Media: water, fire water and other impurities without abrasive or long-fiber impurities and no chemical or mechanical pump for corrosive media.
6. Maximum allowable medium termperature 70℃, the maximum ambient termperature of 40℃.

Technical data

Model	Capacity (m3/h)	Lift head (m)	Speed (r/min)	Motor (KW)	Inlet&Outlet Diameter (mm)
150-400	140 200 260	53 50 44	1450	45	150
150-400A	131 187 243	46.6 44 38.3	1450	37	150
150-400B	122 174 226.5	40 38 33	1450	30	150
150-250(I)	120 200 240	87 80 72	2900	75	150
150-250(I)A	112 187 224	76 70 63	2900	55	150
150-250(I)B	104 173 208	65 60 54	2900	45	150
150-315(I)	120 200 240	133 125 120	2900	110	150
150-315(I)A	112 187 224	116 110 105	2900	90	150
150-315(I)B	104 173 208	100 95 91	2900	75	150
200-200	140 200 260	13.8 12.5 10.6	1450	15	200
200-200A	125 179 232.5	11 10 8.5	1450	11	200
200-250	140 200 260	21.8 20 17	1450	18.5	200
200-250A	129 184.4 240	18.5 17 14.4	1450	15	200
200-250B	117 167 217.5	15.2 14 12	1450	11	200
200-315	140 200 260	33.8 32 28	1450	30	200
200-315A	131 189 243	29.5 28 24.5	1450	22	200
200-315B	121 173 225	25 24 21	1450	18.5	200
200-400	140 200 260	53 50 44	1450	45	200
200-400A	131 187 243	46.6 44 38.3	1450	37	200
200-400B	122 174 226.5	40 38 33	1450	30	200
200-400C	112 160 208	34 32 28	1450	22	200
200-200(I)	280 400 520	13.4 12.5 10.5	1450	22	200
200-200(I)A	250 358 465	10.7 10 8.5	1450	18.5	200
200-250(I)	280 400 520	22.2 20 14	1450	30	200
200-250(I)A	250 358 465	18 14 11.2	1450	22	200
200-250(I)B	226 322 419	14.4 13 7.3	1450	18.5	200
200-315(I)	280 400 520	36 32 26	1450	55	200
200-315(I)A	262 374 486	31.5 28 23	1450	45	200
200-315(I)B	242 346 450	27 24 19.5	1450	37	200
200-400(I)	280 400 520	54.5 50 39	1450	75	200
200-400(I)A	362 374 486	48 44 34	1450	75	200
200-400(I)B	242 346 450	41.4 38 29.6	1450	55	200
200-400(I)C	224 320 416	34.9 32 25	1450	45	200
250-250	350 550 650	22 20 16	1450	45	250
250-250A	300 500 600	18.3 17 14	1450	37	250
250-235	300 500 600	14 12.5 11	1480	22	250
250-300	300 500 600	22 20 16	1480	37	250
250-315	350 550 650	34 32 28	1450	75	250
250-315A	300 500 600	29.5 28 24	1450	55	250
250-315B	260 450 520	25 24 20	1450	45	250
250-400	300 500 600	54.5 50 39	1480	90	250
300-235	540 720 900	20.5 18 15.0	1450	55	300
